KARA L-ACOUSTICS (SET OF 03)

• The KARA modular line source operates on the 55 Hz - 20 kHz frequency band. The frequency response can be extended up to 32 Hz with the SB18 sub-bass reinforcement.
• KARA is a 2-way active loudspeaker comprising two 8” neodymium LF drivers mounted in a bass-reflex enclosure. The HF section is composed of a neodymium driver with a 3” diaphragm compression chamber loaded by a DOSC® waveguide.
• The coplanar K-configuration of the transducers defines a horizontal polar coverage of 1 10 °, symmetrical with respect to the projection axis and without secondary lobes over the entire frequency band. The combination of a coplanar geometry and the DOSC® waveguide makes it possible to fulfill the five criteria of the WST®. The wave front of a KARA line can be modeled without breaking and without accident up to a maximum of 10 ° per element placed in line.
• The KARA loudspeaker is made of premium Baltic birch plywood with outstanding mechanical and acoustic properties. The four-point rigging system allows up to 24 KARA loudspeakers to be hung in a single row.
• The KARA loudspeaker is driven and amplified by the dedicated L-ACOUSTICS LA8 controller which provides linearization, intelligent protection, and optimization in three operating modes:

1. “WIDEBAND” mode when using main source line or distributed system.
2. The “HIGH-PASS” mode as a proximity reinforcement or as a downfill of the K1 system.
3. The “LOW EXTENSION” mode in use with the SB18.
4. The performance of a KARA loudspeaker depends on the preset used and the configuration chosen.

Technical data

• Useful bandwidth (- 10 dB): 55 Hz - 20 kHz (preset [KARA])
• Nominal directivity (-6dB): Horizontal: Symmetrical 1 10 ° Vertical: Depending on the number of elements and the curvature of the source line
• SPL level: 139 dB (preset [KARA])
• Allowable long-term RMS: LF: 450 WHF: 80 W
• Transducers: LF: 2 x 8'' neodymium, treated against humidity HF: 1 x 3'' neodymium driver with compression chamber and diaphragm Nominal impedance: LF = 8 ohms, HF = 8 ohms
• Hooking: High resistance steel, certified for 24 KARA (BGV-C1 compliant) Angular steps: 0, 1, 2, 3, 4, 5, 7.5, 10 °
• Connectors: 2 Speakon® 4-point sockets
• Material: Baltic Birch Plywood
• Finish: RAL 8019® brown-grey paint
• Front face: steel grille with polyester powder coating, black acoustically neutral airnet® fabric Hanging: steel with double polyester and zinc powder coating
