Inputs Mono-Inputs (Mic/Line) with Inserts: 24 Stereo-Line/Mono-Mic-Input Channels: 4/4 Stereo-Effect-Returns (Line): 4 Stereo-Tape-Return (Line): 1 left/right busses Subgroups: 4 To Pre-Fader (Monitor): 2 At Post-Fader (Effects): 2 Aux Switchable Pre/Post-Fader: 2 Master L/R: 2 Mono-PFL: 1 Stereo AFL: 2 outputs Subgroups (with Inserts): 4 impedanced balanced 1/4 inch jacks Aux Pre-Fader (Monitor): 2 XLR (balanced) Aux Post-Fader (Effects): 2 impedanced balanced 1/4 inch jacks Aux switchable Pre/Post-Fader: 2 XLR (balanced) Master (with inserts): 2 XLR (balanced) Master B Out: 2 XLR (balanced) (switchable Mono/Stereo, pre-post Fader) Tape Send (Recording): 1 Stereo (Phono) Direct Outputs (1/4 inch Jack): 24 Stereo-Headphones: 2 Stereo-1/4 inch jack Stereo-Speakers: 2 impedanced balanced 1/4 inch jacks Input Impedance Mic 2kΩBalanced Line 20kΩBalanced Input Gain Mic Continuously variable 0dB to +60dB Line (Mono Channel) Continuously variable -20dB to +40dB Line (Stereo Channel) Continuously variable - 10 dB to +20dB Line Level Inputs 0dB Maximum Input Level Microphone and Line +22dBu Line Level Inputs (Mono) +42dBu Line Level Inputs (Stereo) +22dBu CMR at 1kHz Mic (Gain +30dB) > 80dB Line > 40dB CMR at 10 0Hz Mic (Gain +30dB) 70dB typical Frequency Response(20Hz-20kHz) Mic to Mix (Gain +60dB) + 0dB to -1dB Noise (20Hz-20kHz) Mic EIN ref. 150Ωgain +60dB -129dBu Mic EIN ref. 150Ωgain 0dB - 10 7dBu System Noise(20Hz-20kHz) Summing Noise (12 channels routed, faders down) -90dBu Line to Mix Noise (12 channels routed at 0dB) -84dBu Distortion at 1kHz Mic to Insert (+30dB Gain. +20dBu Output) Typ 0.0007% Mic to Master (+30dB Gain, +20dBu Output) Crosstalk at 1kHz Channel-to-Channel Mix-to-Mix Channel to Mix Fader Attenuation> 10 0dB Switch Rejection > 10 0dB Output Impedance Line Outputs 75Ωbalanced Headphones to drive 32Ω Maximum Output Level Master Outputs +25dBu Line Outputs +22dBu Headphones +22dBu / 600Ω Nominal Signal Level Microphone - 60dBu to 0dBu Line 0dBu Mono Channel Equalizer Hi Pass Filter 2nd order Butterworth, 80Hz Treble +/-15dB at 12kHz (Shelv) Hi Mid Continuously variable 10 0Hz to 2kHz (1 Oct) +/-15dB Lo Mid Continuously variable 400Hz to 8kHz (1 Oct) +/-15dB Bass +/-15dB at 80Hz (Shelv) Equalizer Stereo Channel Treble +/-15dB at 12kHz (Shelv) Hi Mid 3kHz (1.4 Oct) +/-15dB Lo Mid 300Hz (1.4 Oct) +/-15dB Bass +/-15dB at 80Hz (Shelv)
